Model ENAI-D150H150/5T01 NaI(Tl) Gamma Scintillation Detector

The model ENAI-D150H150/5T01 NaI(Tl) scintillation detector is a hermetically sealed assembly which includes a high resolution diameter 150mm x 150mm length NaI(Tl) crystal, a diameter 130mm photomultiplier tube, an internal magnetic light shield, an aluminum housing and a 14 pin connector.

ENAI-D150H150/5T01 NaI(Tl) Sintillation Detector Specifications

1. Scintillation crystal: NaI(Tl) diameter 150mm x 150mm
2. PMT: Beijing Hamamatsu diameter 130mm ET 9390KB

3. Energy resolution: ≤ 8.5% at Cs137
4. Working temperature: -20 ℃ to +65 ℃
5. High Voltage: 400V ~ 1100V

ENAI-D150H150/5T01 NaI(Tl) Scintillation Detector Outer dimension
